Turret

Introduce foreign advanced technology and management concept, High precision processing equipment, and High-end measuring instruments; Have a high-quality professional team, Strictly follow the ISO9001-2008 quality control system, Perfect sales network, and good after-sales service, The management platform of informatization interaction, scientific management, standardized specifications, standardized operation, and specialized manufacture, Make a famous brand of "DRAKE".

Our products include rotary cylinders, power chucks, collet chucks, and so on. It can also be made according to the user’s special needs, and provides you with the best-integrated solutions for the clamping mechanism. Depending on “reasonable price, reliable quality, considerate service, constant innovation’’, all of those products have been well recognized by users both old and new, and they are widely applied to NC lathes, common lathes, machining centers, drillers and millers, welding machines, pipe threading machine, production line equipment, and automatic control system, etc.

Please submit your request and email and we'll get back to you within 24 hours!

Our CNC lathe turret is a high-performance tool that offers precision and versatility for a range of turning applications. It features a robust construction with high-strength materials that ensure long-lasting durability and reliable operation. Our turret is designed with advanced technology that enables fast and accurate tool changes, reducing cycle times and increasing productivity. It is available in a variety of sizes and configurations to suit your specific needs, and it can be customized with additional features such as live tooling and automatic tool changers. Our CNC lathe turret is an ideal choice for use in industries such as aerospace, automotive, and medical manufacturing.

CNC Lathe Turret

Vertical tool CNC Turret adopts the working principle of worm gear transmission, face-tooth coupling as fine indexing mechanism, large screw locking and Hall unit sending signal, which has the features of high repeatability, smooth rotation and multi-station. It is the best choice for machining complex parts.

Indexing Turret adopts the working principle of coupling as a fine indexing mechanism. It has the features of high repetition accuracy, indexing without lifting table, and large locking force. It is the ideal product for machining equal parts.

The CNC Turret power rotates with the direct drive motor. It indexes the position by precise three-piece face-tooth coupling and hydraulic clamping/unclamping of the tool holder disc. It features high rigidity, instant response, high control accuracy, smooth running from low speed to high speed, intelligent bi-directional indexing and shortest path positioning, multiple tool positions, built-in cooling, etc. It is the best choice for high-grade CNC lathe.

Power Tool CNC Turret is based on Servo Turret and equipped with servo power head. The advantages are fast tool change, high hydraulic locking force, fixed tools can be installed in various positions and rotary tools can also be installed so that the lathe can perform turning, facing, grooving, tapping, milling polygons and putting the top. The shape is held at one time. This Turret is a key component of high-grade CNC turning center.

Selecting Turret Model

1. When selecting the Turret model, please check each parameter. Select the number of stations according to the number and complexity of the part program.

2. Select the tool specification according to the machine tool model and cutting force. Select front type or rear type Turret according to the cutting direction of the machine tool.

3、After the horizontal Turret boring head is installed, bore the inner hole by yourself according to the size of the boring bar and mark it accordingly. When installed later, the tool should be fixed in place.

4. the distance from tool protruding out of the upper casing generally does not exceed 2/3 of the upper casing size. please note when placing an order if the limit is exceeded.

5. It is forbidden to touch with hands or other things when Turret is running to avoid injury or damage.

6. If customers have special requirements or parameter changes, please provide information and contact with our company.
