Jun. 24, 2025
As a leading manufacturer in precision tool components, Drake offers a comprehensive range of products including chucks, turrets, CNC tool holders, rotary cylinders, tool magazines, indexing plates, optical machines, vises, CNC lathes, collet chucks, and angle heads. Our accessories are engineered to deliver superior performance, durability, and precision for various industrial machining applications. Whether you need high clamping force, rapid tool changes, or customizable solutions, Drake ensures seamless integration with your CNC equipment. Explore common questions answered by our experts to help you make informed purchasing and operational decisions.
At Drake, we offer a full range of high-performance chucks engineered to deliver precision, stability, and durability in demanding machining environments. Our product line includes hydraulic chucks, pneumatic chucks, and manual chucks, all designed for secure clamping and optimal torque transmission. Whether you need hollow or solid types, 3-jaw or custom clamping solutions, Drake chucks are compatible with CNC lathes, turning centers, and special-purpose machines. Built with hardened steel and advanced surface treatments, our chucks ensure long service life and high concentricity. Backed by efficient delivery, global service support, and customizable options, Drake chucks are trusted by manufacturers worldwide to enhance productivity and machining accuracy.
A: Chucks are divided into: hydraulic chucks, pneumatic chucks and manual chucks.
A: What is the size of your workpiece? What machine is it used on? Is it hollow or solid? How many claws are needed?
A: It depends on whether your workpiece passes through the chuck.
A: Our chuck installation method is the same as that of Korea, Japan, and Taiwan.
A: 4-24 inch chucks are in stock and shipped as normal. The warranty period is 12 months.
A: Can be sold separately.
Drake’s high-performance CNC turrets are engineered to meet the rigorous demands of modern turning applications, offering reliable indexing, high-speed rotation, and precise positioning. Our turret series includes servo-driven, hydraulic, and electric models with configurations from 4 to 12 stations, suitable for horizontal and vertical lathes. Designed for fast tool change and high repeatability, Drake turrets help manufacturers reduce cycle time and boost machining efficiency. Each unit is constructed with premium alloy steel, precision-ground components, and advanced sealing systems to ensure durability and minimal maintenance. Whether you're integrating into automated production lines or upgrading existing machines, Drake provides flexible solutions with compatible tool holders, motors, and customized mounting options. Trusted by customers worldwide, our turrets are backed by fast delivery, a 12-month warranty, and technical support tailored to your machine model and production goals.
The sending plate and knife holder can be sold separately.
We have the 4, 6, 8, 10, and 12 station numbers.
Both servo motors and electric motors are available. Which one do you specifically need?
Different types of knife holders have different center heights. Please refer to our catalog for selection, or tell us what center height you need.
It depends on the specific type of turret you have chosen. Generally, the turret we sell is equipped with corresponding accessories.
We have both vertical and horizontal turret.
The turret is divided into: power living turret, servo hydraulic turret, electric turret.
The center height of our tool holder is 63, 80, 100, 125 mm. What center height do you need?
Center height: the height from the bottom of the tool holder to the tip of the tool.
Our tool holder has 4, 6, 8, 10, and 12 stations.
The sensor, tool holder, and motor can be sold separately.
Servo hydraulic turret and electric turret are in stock. The power living turret needs to be customized according to your needs. The warranty period is 12 months.
Please confirm with us based on the specific model of the tool holder.
Please confirm with us based on the specific model of the tool holder.
Please confirm with us for the specific replacement content.
Drake CNC tool holders are engineered for precision, rigidity, and versatility across a wide range of turning and milling applications. Built from high-strength alloy steel and machined with strict tolerances, our tool holders deliver excellent stability and repeatability, even under high-speed or heavy-duty cutting conditions. We offer a complete lineup including axial and radial live tool holders, fixed tool holders, boring tool holders, and ER collet holders, compatible with major turret interfaces such as BMT40, BMT55, BMT65, and more. Each unit is available with internal or external coolant systems and locking options to suit diverse machining needs. Whether for high-volume production or custom solutions, Drake provides tool holders that ensure optimal cutting performance, tool life extension, and compatibility with your CNC systems. Supported by in-stock availability, custom manufacturing, and a 2-year warranty, Drake CNC tool holders are trusted by global OEMs and job shops for reliable, high-precision machining.
Internal and External Locking.
The advantage of internal locking is more stable tool clamping and higher precision.
The main body is made of forged steel in one piece.
0 degree and 90 degree driven tool holder.
Fix the tool holder according to the installation requirements of the machine tool using appropriate bolts or fixtures, ensuring that the coaxiality and perpendicularity of the tool holder with the machine tool spindle or turret components meet the requirements. During the installation process, tighten the bolts to the specified torque.
Carefully check the technical parameters of the machine and the specification manual of the tool holder, understand the type, size, and positioning method of the tool turret or spindle interface of the machine tool, and ensure that the interface of the tool holder is completely matched with the machine tool. At the same time, the installation size and space requirements of the knife holder should also be considered.
The tool holder is divided into: 0+90 degree power tool holder, fixed tool holder.
Our tool holders include BMT40, BMT45, BMT55, BMT65, BMT75, and BMT85.
Our tool holders have two cooling methods, external cooling and internal cooling.
Our tool holders have two locking methods, external locking and internal locking.
Which machine model is your tool holder used on?
Standard 0+90 degree and fixed tool holders are available in stock with a 2-year warranty.
No, the chuck of the power tool holder is fixed and cannot be replaced.
Boring tool holder.
Can be used with a reducer and an extension rod. If you want to use an ER32 chuck, you can use a D40-32 reducer and a 32 handle.
No, some models have yellow and black colors.
Yes, please send us the drawing for confirmation. Contact now.
Drake rotary cylinders are designed to provide reliable and precise rotary motion for CNC lathes and automated clamping systems. Engineered with high-quality carbon steel barrels and quenched 40Cr alloy steel piston rods, our rotary cylinders deliver excellent wear resistance, corrosion protection, and long service life. Available in both hollow and solid shaft configurations, they support a wide range of spindle sizes and are compatible with various chuck types. Each cylinder undergoes strict quality control and surface treatments, such as precision honing and chrome plating, to ensure smooth operation under high-speed, high-pressure conditions. With optional sizes ranging from 4 to 15 inches, Drake rotary cylinders are ideal for high-efficiency machining environments requiring fast and stable clamping. In-stock models are available for immediate shipment, and custom solutions can be developed based on your machine type and workholding needs. Backed by a 12-month warranty and professional technical support, Drake rotary cylinders help manufacturers improve safety, efficiency, and machine uptime.
A: The cylinder barrel is made of high-quality carbon steel, which has undergone quenching and tempering treatment and precision honing. The piston rod is made of 40Cr alloy steel, which has undergone quenching and chrome plating treatment, making it wear-resistant and corrosion-resistant.
A: It has good sealing and oil resistance, no leakage risk under rated pressure, and a long service life.
A: Discounts can be given for bulk purchases based on the order quantity, and specific details can be negotiated.
A: Our products have obtained ISO 9001 quality management system certification, CE certification, etc. to ensure that the product quality meets international standards.
A: Supports various installation methods such as flange type and base type, adapting to different mechanical equipment requirements.
A: Cylinders are divided into: 1. Hydraulic cylinders and pneumatic cylinders; 2. Solid cylinders and hollow cylinders.
A: 1. Is your chuck hollow or solid? 2. Do you need to see if your workpiece passes through the cylinder?
A: 4-15 inch cylinder are in stock and shipped as normal. The warranty period is 12 months.
Drake tool magazines are built for fast, reliable tool change in CNC machining centers. Available in carousel (umbrella-type) and chain-type designs, our magazines support 8 to 20 stations and integrate seamlessly with automatic tool changers. Designed for durability, precision, and efficient operation, they improve production speed while minimizing downtime. Custom configurations available upon request.
A: Generally, we have 8 workstations, 10 workstations, 12 workstations, 16 workstations, and 20 workstations.
A: The bracket needs to be purchased separately and customized after the customer provides the model and plans it.
A: Pneumatic.
A: When installing tools, ensure that the handle matches the tool holder clamp of the tool magazine, and the installation accuracy meets the requirements. Insert the tool accurately into the chuck and clamp it with the corresponding clamping device.
A: The single tool changing time of the tool magazine is about 3TC, and it adopts technologies such as dual robotic arms and high-speed transmission mechanism to achieve efficient and fast tool changing.
A: The quotation does not include free installation and debugging services. We provide online technical guidance to ensure the normal operation of the equipment. Contact now.
Drake’s indexing plates are precision-engineered for accurate angular positioning in machining and inspection applications. Available in mechanical, optical, and CNC types, our indexing plates ensure high repeatability and robust performance across gear cutting, keyway milling, and circular machining tasks. Built with durable materials and high-precision components, they offer excellent torque resistance and smooth indexing. Custom sizes and configurations are available to meet your specific equipment needs.
A: The indexing disc usually uses mechanisms such as gears, worm gears, and the indexing disc body to achieve indexing.
A: We have mechanical indexing plates, optical indexing plates, and CNC indexing plates.
A: Of course, our indexing plate is suitable for various workpieces that require angular indexing processing, including circular, polygonal, and parts with circular indexing requirements.
A: The rotational speed of the indexing disc has a certain impact on the indexing. Within a certain range, increasing the rotational speed appropriately can improve production efficiency, but if the rotational speed is too high, it may lead to a decrease in indexing accuracy.
A: 1. Strong anti-interference ability 2. Good durability 3. Instant division 4. Good compatibility with traditional devices
Drake’s optical machines are precision-machined base structures designed for CNC machining centers, VMCs, and gantry-type machines. Available in both linear rail and box-way configurations, our optical machines ensure excellent rigidity, vibration damping, and alignment accuracy. Each unit is optimized for stability during high-speed and heavy-load operations, making it ideal for complex part processing. We offer customization based on machine model, size, and application requirements.
A: We have wire or hard rail milling composite machines.
A: We can provide the relevant accessories, such as turret and tool holders.
A: Firstly, it is necessary to clarify the application scenario and specific requirements. In addition, factors such as the size, weight, and interface type of the optical machine need to be considered to ensure that it can be used in conjunction with other devices.
A: The stability of optical machines is influenced by various factors, including the rigidity of mechanical structures, the thermal stability of materials, changes in environmental temperature and humidity, vibration, etc.
A: Generally by sea.
Drake’s precision vises are built for stable and secure clamping in milling, drilling, and CNC machining operations. Available in mechanical, hydraulic, and pneumatic types, our vises offer strong clamping force, wear resistance, and excellent repeatability. Made from high-strength alloy steel, the jaws are hardened for durability and accuracy under heavy loads. Suitable for both metal and wood applications, Drake vises are ideal for manufacturers seeking efficiency, reliability, and long service life.
A: Vises work through components such as lead screws, nuts, and jaws. When the screw is rotated, the nut will move on the screw, thereby driving the movable jaw to move relative to the fixed jaw, achieving clamping and loosening of the workpiece. The thread fit of the screw and nut can provide a large clamping force, ensuring that the workpiece remains fixed during the machining process.
A: We have mechanical vises, hydraulic vises, and pneumatic vises.
A: The width specifications of vise jaws are diverse, commonly including 50mm, 60mm, 80mm, 100mm, 125mm, 150mm, 200mm, etc.
A: Choose the appropriate installation location, usually on the worktable of the machine tool. Place the vise on the workbench and use fixing devices such as bolts or pressure plates to securely fix the vise on the workbench. Pay attention to making the jaws of the vise parallel or perpendicular to the coordinate axis of the machine tool.
A: Vises are suitable for various types of workpieces, including metal parts of various shapes, plastic parts, wood, etc.
A: 20CrMnTi, which is alloy steel.
Drake’s CNC lathe machines deliver high-precision turning performance for both simple and complex components. Designed with rigid cast iron beds, servo-driven spindles, and advanced control systems, our lathes ensure excellent accuracy, stability, and repeatability. Available in horizontal and vertical configurations, they support a wide range of tooling systems and automation options. Ideal for industries such as automotive, aerospace, and mold manufacturing, Drake CNC lathes help increase productivity while reducing cycle time and manual intervention.
A: We both have the vertical and horizontal lathe.
A: We both have the CNC and manual lathe.
A: 1. High Precision 2. Stable Processing Quality 3. High Degree of Automation 4. High Production Efficiency 5. Strong Capability for Complex Part Machining
A: We are Industry and trade integration.
A: Generally by sea.
Drake’s collet chucks offer high-precision, quick-change clamping solutions for CNC lathes and machining centers. Available in pneumatic, hydraulic, and vertical styles, our collet chucks provide strong gripping force and excellent concentricity, ideal for high-speed, high-accuracy operations. Designed to accommodate various workpiece sizes, they ensure minimal runout and improved machining efficiency. Customizable models and matching accessories, such as collets and claws, are also available to meet specific application requirements.
A: We have hydraulic collet chucks and pneumatic collet chucks.
A: The clamping force of the hydraulic chuck may be around 3000-5000N. The clamping force of pneumatic chuck is usually around 500-3000N.
A: The service life of the chuck is affected by various factors, including the material, manufacturing process, frequency of use, usage environment, and maintenance status of the chuck, so it is difficult to give an exact time.
A: The collet chuck needs to be purchased separately.
A: This chuck can be used in either internal or external clamp configurations.
A: The forward push chuck achieves clamping by pushing forward, using the front push rod to tighten the clamping claw. The pull back chuck achieves clamping by pulling backwards. Pull back chucks typically offer higher positioning accuracy and repeatability, suitable for precision machining, while front push chucks are more widely used where speed and ease of clamping are prioritized over high precision.
A: The collet chucks are divided into: pneumatic collet chucks, hydraulic collet chucks, and vertical collet chucks.
A: What is the size of your workpiece?
A: The chuck body is in stock, but the collet needs to be customized according to the size of your workpiece. The production lead time is about 10-15 days, and the warranty period is 12 months.
A: Collet and claw can be sold separately.
A: Yes, it is one-to-one size.
A: Can be customized according to your drawings.
A: Installation screws and air nozzles, as well as collet wrenches.
A: Yes.
A: Yes, please tell us the speed, clamping accuracy, whether to rotate, clamping force, and processing you need.
Drake’s angle heads are precision accessories designed to extend the machining capabilities of CNC machines by enabling tool operation at various angles. Available in light, 90-degree right-angle, universal, and tilt series, our angle heads ensure high accuracy and smooth transmission through advanced gearing and assembly. Compatible with multiple spindle interfaces like SK, CAT, BT, and HSK, they support maximum rotational speeds up to 8000 rpm. Customizable angles and heights are available to suit diverse machining requirements, backed by reliable performance and a 12-month warranty.
A: Generally, the maximum speed that the angle head can achieve is 8000rpm.
A: We can provide multiple driven handle options, such as HK, HSK, CAT, KM, BT, and NT.
A: The accuracy of the angle head is mainly ensured through high-precision component manufacturing and assembly.
A: Angle head is a type of machine tool accessory, which works by transmitting the rotational motion of the machine tool spindle to the tool through internal transmission mechanisms such as gears and shafts, and changing the axis direction of the tool to form a certain angle with the machine tool spindle axis, thereby achieving machining of workpieces in different angle directions.
A: Firstly, it is necessary to correctly install the machine tool spindle and angle head connecting bolts. During the installation process, specialized installation tools should be used to follow the prescribed installation steps. Attention should be paid to adjusting the position and angle of the angle head. After installation, a trial run should be conducted to check whether the rotation of the angle head is smooth, and whether there are any abnormal noises or vibrations.
A: The adjustable angle of our universal angle head is 360 degrees.
A: Angle head options include: light series, 90 degree right angle series, universal series, and tilt series.
A: SK, CAT, BT, K, NT, HSK, etc.
A: The angle can be customized according to your requirements. We usually produce 30 degrees, 60 degrees, 90 degrees, and universal types.
A: The angle head can be customized according to the height you require.
A: The standard product delivery time is 7–10 days, and the warranty period is 12 months.
A: Can be sold separately.
A: Yes, please provide the interface size.
At Drake, we understand that choosing the right machine tool accessories is critical for achieving optimal machining efficiency and product quality. Our FAQ section covers essential topics such as product specifications, compatibility, installation methods, customization options, delivery timelines, and warranty policies. Supported by industry-leading technology and professional customer service, Drake’s accessories are designed to boost your manufacturing productivity and minimize downtime. Trust Drake for reliable, high-precision components tailored to your specific needs.
Discover how Drake’s machine tool accessories can elevate your machining operations. Contact us today to request a quote or speak with our technical team for personalized solutions.
