Angle head

As a leading angle head manufacturer and supplier, Drake offers high-performance CNC angle heads that enhance the flexibility and capability of your milling and drilling operations. Our angle heads are engineered for precision, durability, and compatibility with a wide range of CNC machine tools.


Designed to extend the machining axis without repositioning the workpiece, Drake angle heads allow tools to operate at fixed or adjustable angles—ideal for complex surface machining, deep hole processing, or multi-angle operations.


Angle Head Key Features

  • High Rotational Speed: Up to 8000rpm

  • Tool Interfaces Available: HSK, BT, CAT, KM, NT

  • Customizable Angle Options: 30°, 60°, 90°, or fully adjustable (0°–360°)

  • High Precision Transmission: Gear-driven system with stable performance

  • Optional Bracket Support: Tailored to your CNC model

  • Durable Housing: Built to withstand high loads and vibration

  • Coolant Support: Optional internal/external cooling channels


Customizable Parameters


As a professional angle head supplier, Drake offers OEM/ODM customization:

ParameterOptions
Max Speed6000–8000 rpm
Input TypesHSK / BT / CAT / KM / NT
Tool Holder ClampingPneumatic or manual
Angle OptionsFixed (30°, 60°, 90°) / Universal (360°)
HeightCustomizable based on machine interface
BracketOptional, made-to-order
Coolant InterfaceOptional water/oil/air flow system


Angle Head Key Features Applications


Drake angle heads are used across industries where multi-directional machining is essential:

  • Automotive engine block machining

  • Aerospace part processing

  • Mold & die production

  • 5-axis conversion on 3-axis machines

  • Slotting, chamfering, and angled hole drilling


Why Choose Drake as Your Angle Head Supplier?


  • One-stop angle head manufacturer & supplier with 10+ years experience

  • ✔ Fast delivery of standard and customized models

  • ✔ OEM/ODM service for international customers

  • ✔ Precision manufacturing with strict QC standards

  • ✔ Online technical support and documentation


Looking for a reliable angle head supplier for your CNC machining center? Contact Drake today for a quote, technical consultation, or OEM design support. Our team is ready to help you upgrade your production with precision-engineered CNC angle heads.


Angle Head FAQ

Q1: What is the maximum rotational speed of your angle head?
A1: Generally, the maximum speed our angle head can achieve is 8000 rpm.


Q2: What input options can you provide for the angle head?
A2: We offer a variety of drive handle types, including HK, HSK, CAT, KM, BT, and NT.


Q3: How is the accuracy of the angle head ensured?
A3: The accuracy is mainly guaranteed through high-precision component manufacturing and precise assembly processes.


Q4: What is the working principle of an angle head?
A4: An angle head is a machine tool accessory that transmits the spindle’s rotational motion to the tool through internal gears and shafts. It changes the axis of the tool to a specific angle relative to the spindle axis, enabling multi-angle machining operations on the workpiece.


Q5: What should be noted when installing the angle head on a machine tool?
A5: Ensure correct installation of the connecting bolts between the spindle and the angle head. Use specialized tools and follow proper installation procedures. Adjust the position and angle accurately, and perform a trial run after installation to check for smooth rotation and the absence of abnormal noise or vibration.


Q6: What is the maximum adjustable angle of your angle head?
A6: Our universal angle head allows for a fully adjustable angle of up to 360 degrees.


Q7: How can I choose the right angle head model?
A7: We offer various types of angle heads, including light-duty series, 90-degree right-angle series, universal series, and tilting series. The selection depends on your machining needs and application environment.


Q8: What drive handle models are available?
A8: Available options include SK, CAT, BT, K, NT, and HSK.


Q9: Can the angle of your angle head be customized?
A9: Yes, we can customize the angle according to your requirements. Commonly produced angles include 30°, 60°, 90°, and fully adjustable universal heads.


Q10: Can the height of the angle head be customized?
A10: Yes, the height can be customized based on your required dimensions.


Q11: What is your typical delivery time and warranty period?
A11: For standard products, the delivery time is 7–10 days. The warranty period is 12 months from the date of delivery.


Q12: Can the accessories for the angle head be sold separately?
A12: Yes, all accessories can be purchased individually.


Q13: Do you support full customization of the angle head?
A13: Yes, we offer full customization services. Please provide the interface dimensions and specific requirements for evaluation. Please submit your request and email and we'll get back to you within 24 hours!
